Mapping Libraries: A Practical Comparison

Choosing a mapping library is an architecture decision rather than a preference. The library determines how much data a map holds before it stutters, whether styling can change at runtime, what the project pays for once traffic grows, and how hard it will be to move away later. This comparison covers the libraries that between them cover almost every web mapping project, and it answers the direct comparisons that come up most often.

The Libraries at a Glance

Library	Rendering	Dimension	Licence	Best for
Leaflet	DOM and Canvas	2D	BSD 2 Clause	Simple maps, fast delivery, the largest plugin catalogue
MapLibre GL JS	WebGL	2D, extrusions, globe	BSD 3 Clause	Styled vector tile maps without vendor lock in
Mapbox GL JS	WebGL	2D, extrusions, globe	Proprietary from v2	Hosted styling, geocoding, routing and traffic
OpenLayers	Canvas and WebGL	2D	BSD 2 Clause	Projections, OGC services, GIS grade control
CesiumJS	3D engine	True 3D globe	Apache 2.0	Terrain, 3D Tiles, time dynamic scenes
deck.gl	WebGL overlay	2D and 3D	MIT	Hundreds of thousands of records, analytical layers
ArcGIS Maps SDK	Canvas and WebGL	2D and 3D	Commercial	Enterprise GIS inside the Esri ecosystem
Google Maps Platform	Proprietary	2D and limited 3D	Pay per use	Consumer services, places, routing, familiar UX

Rendering Architecture Explains Most Differences

Three rendering families cover every library in the table, and almost every practical difference follows from which family a library belongs to.

Leaflet places tiles and features into the DOM and Canvas. Every feature is an object the browser manages, which makes the library small, predictable and easy to debug, and which ties rendering cost to the CPU. MapLibre, Mapbox and deck.gl compile geometry and styles into GPU buffers, which allows rotation, pitch, runtime restyling and far larger datasets at the cost of a bigger bundle and a WebGL requirement. CesiumJS is a full 3D engine that draws a WGS84 ellipsoid with terrain, a camera and a clock, which is a different problem from drawing a map.

OpenLayers sits deliberately across the first two. It renders with Canvas and WebGL depending on the layer type, which is why it competes with Leaflet on simple maps and with MapLibre on vector tiles.

What the Benchmarks Actually Show

The common claim is that Leaflet degrades past ten thousand features and WebGL is always faster. A 2025 study in the ISPRS International Journal of Geo-Information measured this directly, testing Leaflet 1.9.4, OpenLayers 10.2.1, Mapbox GL JS 3.7.0 and MapLibre GL JS 4.7.1 on datasets from 50 to 500,000 features. The results are more interesting than the folklore:

Up to 5,000 points, Leaflet at roughly 140 ms and OpenLayers at roughly 115 ms were the fastest of the four.
At 50,000 points, Mapbox GL JS led at roughly 467 ms, ahead of OpenLayers at roughly 588 ms.
For lines at 100,000 features, OpenLayers finished in roughly 1,296 ms, close to twice as fast as the others.
For polygons at 50,000 features, Mapbox GL JS was fastest at roughly 1,265 ms.
Past 50,000 features every library crossed one second and grew sharply from there.

The practical reading is that WebGL is not automatically faster at every scale. Below a few thousand features the rendering engine barely affects speed, and the choice should follow styling needs and team familiarity instead. Above roughly fifty thousand features the engine becomes the dominant factor, and that is the point at which a GPU pipeline or a dedicated layer framework stops being optional.

MapLibre vs Leaflet

This is the most frequent comparison, and the two libraries are not really competing for the same job. Leaflet draws raster tiles into the DOM. MapLibre draws vector tiles on the GPU. Everything else follows from that.

Styling is the clearest consequence. A Leaflet map looks the way the tile server rendered it, because the appearance is baked into the images. A MapLibre style is a JSON document, so a night theme, a data driven colour ramp or a hidden layer is a property change in the browser rather than a new tile set on the server. Camera behaviour follows the same split, with rotation, pitch and a globe projection native to MapLibre and absent from Leaflet.

Leaflet answers with weight and reach. It has no dependencies, a very small bundle, the largest plugin catalogue in web mapping, and it runs where WebGL is unavailable. One caveat is worth knowing. Leaflet 2.0 moves to ES modules, drops the global L object and drops legacy browsers, so any project leaning on older plugins should check compatibility before upgrading.

Choose Leaflet when the map shows a basemap, markers and a few overlays, and the shortest path to working software matters most. Choose MapLibre when styling is part of the product, when the data arrives as vector tiles, or when the map has to tilt, rotate or carry tens of thousands of features.

MapLibre vs OpenLayers

Both are open source, both render vector tiles, and both are actively developed. They differ in what they treat as the default job.

OpenLayers is a GIS engine that happens to run in a browser. It handles arbitrary coordinate reference systems through proj4, speaks WMS, WMTS and WFS, reads a long list of formats including GeoTIFF, and gives fine control over layers, controls and interactions. MapLibre is a rendering engine for styled vector maps, and its projection support is effectively Web Mercator plus the globe and vertical perspective projections added in version 5. Reprojecting a national grid is not what it is built for.

The deciding question is usually the coordinate system. A project that must serve a national grid or a polar projection, or that consumes OGC services directly, points to OpenLayers. A styled vector map in Web Mercator points to MapLibre, which reaches the same result with less code and a smoother rendering pipeline. Styling reflects the same difference, with MapLibre using a declarative style specification and OpenLayers using style functions written in JavaScript.

Cesium vs Mapbox

These two are compared often and answer different questions. Mapbox GL JS is a 2D map that extrudes polygons and tilts the camera, which is usually called 2.5D. Buildings are footprints given a height. CesiumJS is a 3D geospatial engine drawing a WGS84 ellipsoid, with global terrain, 3D Tiles for photogrammetry meshes and BIM models, and a simulation clock for time dynamic data such as flight paths or satellite tracks.

The cost difference matches the capability difference. Cesium ships a much larger runtime and takes noticeably longer to reach first render, which is the price of a real 3D engine. Licensing differs too, since CesiumJS is Apache 2.0 with optional Cesium ion hosting, while Mapbox GL JS from version 2 onward is proprietary and billed by map load.

The useful question is whether the project needs a globe or a map. Terrain fly throughs, orbital tracks and large 3D tilesets are Cesium work. A styled city map with extruded buildings is Mapbox or MapLibre work at a fraction of the runtime cost.

Licensing and Why MapLibre Exists

In December 2020 Mapbox released GL JS version 2 under a proprietary licence that requires a Mapbox access token and bills by map load. The community forked the last BSD licensed release, 1.13, and that fork became MapLibre GL JS. The history matters because it explains the present situation:

MapLibre is a practical migration target for older Mapbox GL JS projects and works against any vector tile source.
Mapbox stays attractive when the hosted stack is the point, covering Studio, geocoding, directions and traffic.
Google Maps and the ArcGIS Maps SDK bill per use or per licence, with quotas that shape architecture at scale.

Licensing is the constraint teams discover last, usually at the moment traffic starts to grow. It deserves a decision at the start rather than a surprise later.

Where deck.gl Fits

deck.gl is not a map library and does not replace one. It is a GPU layer framework that draws on top of MapLibre, Mapbox or a Cesium scene, and it exists for the cases where the data volume is the problem. Heatmaps, arc and flow maps, hexagon aggregation and scatterplots of hundreds of thousands of records are its normal workload. The usual production pairing is MapLibre for the basemap and interaction with deck.gl handling the analytical layers above it.

When Google Maps or ArcGIS Is the Right Answer

Google Maps Platform makes sense when the product needs places data, routing and an interface users already recognise, and when deep cartographic control is not a requirement. The trade is limited styling freedom and a cost model tied to usage.

The ArcGIS Maps SDK makes sense when the organisation already runs Esri infrastructure and the map is a front end to enterprise data and spatial analysis. It offers the broadest analytical toolset of anything in this comparison, and it expects licensing and integration to match.

How to Choose

Working through these in order settles most projects:

A 2D map with markers and a small dataset points to Leaflet.
A styled vector map without vendor lock in points to MapLibre GL JS.
Hosted styling, geocoding and routing in one contract point to Mapbox.
Non Mercator projections or OGC services point to OpenLayers.
A true globe, terrain or 3D Tiles points to CesiumJS.
More than fifty thousand records on screen points to deck.gl over a WebGL basemap.
An existing Esri estate points to the ArcGIS Maps SDK.

Common Mistakes

Choosing a 3D engine for what is a 2.5D requirement. Extruded buildings do not need a globe.
Assuming WebGL is faster at every scale. Below a few thousand features it is not, and the benchmark numbers above show why.
Deferring the licensing question. Map load billing and API quotas change architecture, and they surface when traffic grows rather than during the prototype.
Sizing the library for today's dataset. Data volume tends to grow in one direction only.
Treating deck.gl as a map library. It needs a basemap underneath it.
Upgrading Leaflet without checking plugins. Version 2 drops the global L object and legacy browser support.

FAQs

Is MapLibre a drop in replacement for Mapbox GL JS?

For projects built on Mapbox GL JS version 1 it is very close, since MapLibre forked from that codebase. Moving from version 2 or later takes real work, because the newer Mapbox releases added features and API changes that MapLibre implemented differently or not at all.

Which is faster, MapLibre or Leaflet?

It depends entirely on data volume. With a few thousand features Leaflet is competitive and sometimes quicker, because there is less to set up on the GPU. With tens of thousands of features and continuous panning or zooming, MapLibre is the clear winner.

Can OpenLayers do everything MapLibre does?

Close to it for rendering vector tiles, and rather more in terms of projections, formats and OGC support. What OpenLayers does not offer is the MapLibre style specification, so styling is written as code rather than declared as a document that designers and servers can share.

Do I need CesiumJS for 3D?

Only for true 3D. Extruded buildings, a tilted camera and a globe view are available in MapLibre and Mapbox at a far lower runtime cost. Global terrain, 3D Tiles and time dynamic scenes are where Cesium becomes necessary.

Can two libraries be used in the same application?

Yes, and it is common. deck.gl over MapLibre is a standard pairing, and many products use a light 2D library on list and dashboard screens with a heavier WebGL map on the main analytical view.
